Technical Specification
Maximum wheel weight65 kg
Maximum wheel diameter39" (990 mm)
Maximum wheel width21" (533 mm)
Rim diameter10" to 24" (254 mm to 610 mm)
Rim width1.5" to 20" (38 mm to 508 mm)
Rim distance
By distance measuring rod
by keypad entry
4 mm to 178 mm
4 mm to 550 mm
Resolution
Fine mode
Normal mode
1 gm5 gm
Minimum unbalance detection
Rim diameter upto 16.3"
Rim diameter above16.3"upto24" Fine Normal
4 gm 10 gm
9 gm 20 gm
Maximum unbalance measurement
300 gmAccuracy1 gm
Position accuracy± 1°
Balancing speed200 RPM
Spin timeMin. 9 sec.
Power Supply230V ±10% AC, Single phase, 50Hz Power0.35HP
